Cisco AIR-ANT2566D4M-RS Dual-Band 6 dBi 4-Element MIMO Outdoor Antenna
In Stock
1 units available
SKU
AIR-ANT2566D4M-RS-REFURBISHED
MPN
AIR-ANT2566D4M-RS
A$300.00
A$272.73
Refurbished Cisco Aironet AIR-ANT2566D4M-RS is a four-element dual-band (2.4/5 GHz) MIMO directional array antenna with self-identifying capability, an IP67 outdoor-rated housing, and four RP-TNC connectors for 4x4 MIMO access points.
In Stock
Brand
Cisco
Model
AIR-ANT2566D4M-RS
Device Type
Dual-Band MIMO Directional Array Antenna
Frequency
2.4 GHz / 5 GHz
Gain
6 dBi
Connectors
4x RP-TNC
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
AIR-ANT2566D4M-RS
Cisco AIR-ANT2566D4M-RS Dual-Band 6 dBi 4-Element MIMO Outdoor Antenna REFURBISHED
Refurbished Cisco Aironet AIR-ANT2566D4M-RS is a four-element dual-band (2.4/5 GHz) MIMO directional array antenna with self-identifying capability, an IP67 outdoor-rated housing, and four RP-TNC connectors for 4x4 MIMO access points.
The AIR-ANT2566D4M-RS is the self-identifying ("-RS") variant of Cisco's AIR-ANT2566D4M four-element dual-band directional array antenna. It delivers a peak gain of 6 dBi across the 2.4 GHz and 5 GHz bands with 4x4 MIMO through four RP-TNC connectors. Its IP67-rated, ruggedized enclosure withstands a -40 to 70 degrees C operating range, making it suitable for outdoor and industrial deployments, and its self-identifying feature allows Cisco Catalyst 9800 controllers (IOS-XE 17.4.1+) to detect it automatically.
Key Features
- Four-element dual-band MIMO directional array antenna (2.4 GHz and 5 GHz)
- Peak gain of 6 dBi in both frequency bands
- IP67-rated ruggedized enclosure for outdoor/industrial use
- Wide operating temperature range of -40 to 70 degrees C
- Self-identifying design detected by Cisco Catalyst 9800 controllers (IOS-XE 17.4.1+)
- Four RP-TNC connectors with 3-foot integrated cables for 4x4 MIMO
- VSWR of 2:1 and 50-ohm nominal impedance
- Directional coverage pattern for targeted, longer-range links
Documents
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
| General | |
|---|---|
| Brand | Cisco |
| Part Number | AIR-ANT2566D4M-RS |
| Antenna Type | Four-element dual-band MIMO directional array |
| Self-Identifying | Yes (detected by Catalyst 9800, IOS-XE 17.4.1+) |
| Performance | |
| Frequency Range | 2.4 GHz and 5 GHz (dual-band) |
| Peak Gain | 6 dBi (both bands) |
| VSWR | 2:1 |
| Nominal Impedance | 50 ohms |
| MIMO | 4x4 (four elements) |
| Physical | |
| Connectors | Four RP-TNC with 3 ft (0.91 m) cables |
| Environmental Rating | IP67 |
| Operating Temperature | -40 to 70 degrees C |
| Mounting | Wall / pole mount (directional) |
| Compatibility | |
| Access Points | Cisco Aironet 1830, 1850, 2800, 3800; Catalyst 9115AX, 9120AX, 9130AX |
Write Your Own Review
Common questions about the Cisco AIR-ANT2566D4M-RS Dual-Band 6 dBi 4-Element MIMO Outdoor Antenna.
Yes, it has an IP67-rated enclosure and a -40 to 70 degrees C operating range for outdoor and industrial deployments.
It provides a peak gain of 6 dBi in both the 2.4 GHz and 5 GHz bands.
It is the self-identifying variant that Cisco Catalyst 9800 controllers running IOS-XE 17.4.1 or later can automatically detect.
No documents available for this product yet.
