*New Sealed* Cisco C-ANT9103 2.4/5/6 Ghz 8-Port Directional Antenna
In Stock
1 units available
SKU
C-ANT9103-NEW
MPN
C-ANT9103
A$1,083.00
A$984.55
New Cisco Catalyst C-ANT9103 8-element MIMO dual-band polarization-diverse directional patch antenna covering 2.4-2.484 GHz and 5.15-7.125 GHz at 6 dBi peak gain, with an eight-port DART connector, built-in EEPROM self-identification and wall or pole mounting.
In Stock
Brand
Cisco
Product Type
Wi-Fi Patch Antenna
Series
Cisco Catalyst C-ANT9103
Antenna Type
Dual-Band Polarization-Diverse Directional Patch
Elements
8-Element MIMO
Frequency Range (2.4 GHz)
2.4-2.484 GHz
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
C-ANT9103
*New Sealed* Cisco C-ANT9103 2.4/5/6 Ghz 8-Port Directional Antenna NEW
New Cisco Catalyst C-ANT9103 8-element MIMO dual-band polarization-diverse directional patch antenna covering 2.4-2.484 GHz and 5.15-7.125 GHz at 6 dBi peak gain, with an eight-port DART connector, built-in EEPROM self-identification and wall or pole mounting.
The Cisco Catalyst C-ANT9103 is an 8-element MIMO dual-band, polarization-diverse directional patch antenna for Cisco Catalyst series access points. It operates across the 2.4-2.484 GHz band and the extended 5 GHz band (5.15-7.125 GHz) with 6 dBi of peak gain on each band, and connects through an eight-port DART interface. A built-in EEPROM lets a compatible access point automatically read the antenna type, gain and beamwidth, and the antenna can be wall- or pole-mounted for indoor or outdoor deployment.
Key Features
- 8-element MIMO dual-band polarization-diverse directional patch antenna
- Covers 2.4-2.484 GHz and 5.15-7.125 GHz bands
- 6 dBi peak gain on both 2.4 GHz and 5 GHz
- Eight-port DART connector interface
- Built-in EEPROM for automatic antenna self-identification
- Wall or pole mountable for indoor and outdoor use
Documents
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
| General | |
|---|---|
| Brand | Cisco |
| Series | Cisco Catalyst C-ANT9103 |
| Technical | |
| Product Type | Wi-Fi Patch Antenna |
| Antenna Type | Dual-Band Polarization-Diverse Directional Patch |
| Elements | 8-Element MIMO |
| Frequency Range (2.4 GHz) | 2.4-2.484 GHz |
| Frequency Range (5/6 GHz) | 5.15-7.125 GHz |
| Peak Gain (2.4 GHz) | 6 dBi |
| Peak Gain (5 GHz) | 6 dBi |
| Connector | DART (8 dual-band ports) |
| Nominal Impedance | 50 Ohms |
| Self-Identification | Built-in EEPROM |
| Physical | |
| Mounting | Wall or pole (2-5 in diameter) |
| Environment | Indoor and Outdoor |
Write Your Own Review
Common questions about the *New Sealed* Cisco C-ANT9103 2.4/5/6 Ghz 8-Port Directional Antenna.
It is an 8-element MIMO dual-band, polarization-diverse directional patch antenna.
It covers 2.4-2.484 GHz and the extended 5 GHz band from 5.15 to 7.125 GHz.
It provides 6 dBi of peak gain on both the 2.4 GHz and 5 GHz bands.
It uses an eight-port DART connector interface.
Yes, it has a built-in EEPROM so a compatible access point can automatically read the antenna type, gain and beamwidth.
