*Brand New* Cisco C9120AXE-E Dual Band 802.11ax External Antennas Access Point

In Stock
1 units available
SKU
C9120AXE-E-NEW
MPN
C9120AXE-E
Be the first to review this product
A$1,847.00 A$1,679.09
New Cisco Catalyst 9120AXE Wi-Fi 6 (802.11ax) access point with 4x4:4 MU-MIMO and four spatial streams, external antennas (E regulatory domain), a 2.5 Gbps Multigigabit uplink and up to 5.38 Gbps aggregate 802.11ax data rate for demanding enterprise wireless.
Main Image Also available REFURBISHED Cisco C9120AXE-E Dual Band 802.11ax 5.38 Gbit/s External Antennas AP Bluetooth 5
A$1,046.00 A$950.91
In Stock
Brand Cisco
Series Cisco Catalyst 9120AX
Wireless Standard Wi-Fi 6 (802.11ax)
Antenna External (E regulatory domain)
MIMO 4x4:4 downlink MU-MIMO (four spatial streams)
Max Data Rate (802.11ax) 5.38 Gbps

Request a quote or add to cart — pricing available on enquiry for refurbished stock.

For international customers, please contact us for personalised support and assistance.

Request Quote / Enquire
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Add to Wish List Add to Compare
C9120AXE-E
*Brand New* Cisco C9120AXE-E Dual Band 802.11ax External Antennas Access Point NEW
New Cisco Catalyst 9120AXE Wi-Fi 6 (802.11ax) access point with 4x4:4 MU-MIMO and four spatial streams, external antennas (E regulatory domain), a 2.5 Gbps Multigigabit uplink and up to 5.38 Gbps aggregate 802.11ax data rate for demanding enterprise wireless.
The Cisco Catalyst 9120AXE is an enterprise-grade Wi-Fi 6 (802.11ax) access point designed for high-density environments and equipped with external antenna connectors (E regulatory domain). It provides 4x4 downlink MU-MIMO with four spatial streams, aggregate data rates up to 5.38 Gbps on 802.11ax, and a 2.5 Gbps Multigigabit uplink for high-throughput deployments. With a flexible radio, Cisco RF ASIC and support for modern PoE standards, it is built for reliable, high-performance enterprise wireless.
Key Features
  • Wireless Standard: Wi-Fi 6 (802.11ax), backward compatible with 802.11a/g/n/ac
  • MIMO: 4x4:4 downlink MU-MIMO (four spatial streams)
  • Antennas: External (E regulatory domain), up to 6 dBi gain
  • Peak Data Rate: Up to 5.38 Gbps (802.11ax)
  • Uplink: 100/1000/2500 Mbps Multigigabit (IEEE 802.3bz)
  • Power: 802.3at PoE+, 802.3bt and 802.3af
  • Memory: 2048 MB DRAM, 1024 MB flash
Specifications
General
BrandCisco
SeriesCisco Catalyst 9120AX
Wireless StandardWi-Fi 6 (802.11ax)
AntennaExternal (E regulatory domain)
Networking
MIMO4x4:4 downlink MU-MIMO (four spatial streams)
Max Data Rate (802.11ax)5.38 Gbps
Max Data Rate (802.11ac)3.47 Gbps
Max Transmit Power (5 GHz)26 dBm
Ports
Uplink Port1x 100/1000/2500 Mbps Multigigabit Ethernet (IEEE 802.3bz)
External Antenna GainUp to 6 dBi (2.4 GHz and 5 GHz)
Physical Power
PoE / Power802.3at PoE+, 802.3bt, 802.3af
System Memory2048 MB DRAM
Flash1024 MB
Dimensions (WxLxH)21.6 x 21.6 x 5.1 cm (8.5 x 8.05 x 2.0 in)
Operating Temperature-20 to 50 degC (-4 to 122 degF)

Documents

Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.

Related Articles

Reviews
Write Your Own Review
You're reviewing:*Brand New* Cisco C9120AXE-E Dual Band 802.11ax External Antennas Access Point
Your Rating
FAQ

Common questions about the *Brand New* Cisco C9120AXE-E Dual Band 802.11ax External Antennas Access Point.

It supports Wi-Fi 6 (802.11ax) and is backward compatible with 802.11a/g/n/ac.
It supports 4x4 downlink MU-MIMO with four spatial streams.
It delivers aggregate rates up to 5.38 Gbps on 802.11ax and up to 3.47 Gbps on 802.11ac.
It uses a single 100/1000/2500 Mbps Multigigabit Ethernet (IEEE 802.3bz) uplink port.
It can be powered via 802.3at PoE+, 802.3bt or 802.3af Power over Ethernet.
