Cisco Catalyst 9300 48-Port mGig Network Advantage Switch – New | C9300X-48TX-A
In Stock — Ready to Ship
1 units available
SKU
C9300X-48TX-A-NEW
MPN
C9300X-48TX-A
A$15,362
The Cisco Catalyst 9300 48-port mGig switch is new and ideal for enterprise networks. It features 48 mGig ports, 2000 Gbps switching capacity, and 715W power supply.
In Stock — Ready To Ship
General
- Device Type: Switch - 48 ports - L3 - managed - stackable
- Enclosure Type: Rack-mountable
Ports & PoE
- Ports: 48 x 100/1000/2.5G/5G/10GBase-T RJ-45
- PoE Budget: Up to 36 ports of 90W UPOE+
Performance & Capacity
- Switching Capacity: 2000 Gbps
- Forwarding Rate: 1488 Mpps
Power
- Power Provided: 715 Watt
- Voltage Required: AC 100-240 V (50 - 60 Hz)
Physical
- Width: 444.5 mm
- Depth: 482.6 mm
- Height: 43.9 mm
- Weight: 14.59 lbs
Environmental
- Max Operating Temperature: 113 °F
- Min Operating Temperature: 23 °F
- Humidity Range Operating: 5 - 90% (non-condensing)
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300X-48TX-A 48-Port mGig Switch New
Optimise your network with high-performance connectivity.
Overview
The Cisco Catalyst 9300 48-port mGig switch is designed for dynamic enterprise networks. Built on the advanced UADP 2.0 ASIC, it supports high-density stacking and flexible uplink options. This switch is ideal for environments where secure and high-speed connections are essential for a hybrid workforce.
Key Features
- High-Density Stacking: Supports up to 1TB of stacking bandwidth with StackWise-1T technology.
- Flexible Uplinks: Offers modular uplink options including 100G, 40G, 25G, and 10G.
- mGig Ports: Features 48 mGig ports for enhanced data throughput.
- Power over Ethernet: Up to 36 ports of 90W UPOE+ for high-power devices.
- Secure Connectivity: Supports 100G IPsec in hardware for secure tunnelling.
- Enhanced Application Hosting: Equipped with additional RAM and AppGig ports for application support.
- Environmental Resilience: Operates in a wide temperature range with a robust design.
Specifications
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Ports | 48 x 100/1000/2.5G/5G/10GBase-T RJ-45 |
| PoE Budget | Up to 36 ports of 90W UPOE+ |
| Performance & Capacity | |
| Switching Capacity | 2000 Gbps |
| Forwarding Rate | 1488 Mpps |
| Power | |
| Power Provided | 715 Watt |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Physical | |
| Width | 444.5 mm |
| Depth | 482.6 mm |
| Height | 43.9 mm |
| Weight | 14.59 lbs |
| Environmental | |
| Max Operating Temperature | 113 °F |
| Min Operating Temperature | 23 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.1BA, IEEE 802.1ae, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3an |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300 48-Port mGig Network Advantage Switch – New | C9300X-48TX-A.
The switch features 48 mGig ports in standalone mode and can support up to 448 mGig ports in an 8-member stack.
Yes, it supports 100G IPsec in hardware for secure tunnelling.
The switch has a power consumption of 715 Watts.
The switch dimensions are 444.5 mm wide, 482.6 mm deep, and 43.9 mm high.
The maximum operating temperature is 113 °F.
Yes, it supports stacking with up to 1TB of bandwidth using StackWise-1T technology.
