Cisco Catalyst 9300X 48-Port mGig Data Only Switch – New | C9300X-48TX-E
In Stock — Ready to Ship
1 units available
SKU
C9300X-48TX-E-NEW
MPN
C9300X-48TX-E
A$11,244
The Cisco Catalyst 9300X is a new 48-port mGig switch designed for enterprise networks. It offers 1TB stacking bandwidth, 2000 Gbps switching capacity, and 48 multigigabit ports.
In Stock — Ready To Ship
Device Type
Switch - 48 ports - L3 - managed - stackable
Enclosure Type
Rack-mountable
Interfaces
48 x 100/1000/2.5G/5G/10GBase-T RJ-45, 1 x USB 2.0
Switching Capacity
2000 Gbps
Switching Capacity with Stacking
3000 Gbps
Forwarding Rate
1488 Mpps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300X-48TX-E 48-Port mGig Switch New
Optimized for high-density enterprise access networks.
Overview
The Cisco Catalyst 9300X is a leading stackable enterprise access switch designed for modern hybrid networks. It supports high-density scenarios, IoT, and cloud integration. With advanced security features and flexible uplink options, it is ideal for organizations looking to enhance their network infrastructure.
Key Features
- High Stacking Bandwidth: Up to 1TB with StackWise-1T technology.
- Flexible Uplinks: Supports 100G, 40G, 25G, Multigigabit, 10G, and 1G options.
- Multigigabit Ports: 48 ports supporting 100/1000/2.5G/5G/10GBase-T.
- High Switching Capacity: 2000 Gbps, with 3000 Gbps when stacked.
- Advanced Security: Supports IPsec tunnel with AES-256 encryption.
- Enhanced Application Hosting: Capable of hosting multiple applications with increased RAM.
Specifications
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Interfaces | 48 x 100/1000/2.5G/5G/10GBase-T RJ-45, 1 x USB 2.0 |
| Performance & Capacity | |
| Switching Capacity | 2000 Gbps |
| Switching Capacity with Stacking | 3000 Gbps |
| Forwarding Rate | 1488 Mpps |
| Forwarding Rate with Stacking | 2232 Mpps |
| IPv4 Routing Table Entries | 39000 |
| Multicast Routes | 8000 |
| VLAN IDs | 4094 |
| Memory | |
| RAM | 16 GB |
| Layer & Routing | |
| Routing Protocols | MSTP, static IP routing, RIP-1, RIP-2, RIPng, PIM-SM, PIM-SSM, GRE, policy-based routing (PBR), STP, VRRP, LISP |
| Stacking | |
| Max Units in a Stack | 8 |
| Interfaces & Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Power Provided | 715 Watt |
| Physical | |
| Width | 17.5 in |
| Depth | 22 in |
| Height | 1.7 in |
| Weight | 14.59 lbs |
| Environmental | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Compliance | |
| Compliant Standards | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, FCC CFR47 Part 15 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300X 48-Port mGig Data Only Switch – New | C9300X-48TX-E.
The Catalyst 9300X supports a maximum of 8 units in a stack.
It supports flexible uplink options including 100G, 40G, 25G, Multigigabit, 10G, and 1G.
The total switching capacity is 2000 Gbps, which increases to 3000 Gbps when stacked.
The switch features 48 multigigabit ports supporting various speeds.
It includes secure tunnel connectivity supporting IPsec tunnel with AES-256 encryption.
The switch is equipped with 16 GB of RAM.
