Cisco Catalyst 9400 1-Port Supervisor Module – New | C9400-SUP-1
The Cisco Catalyst 9400 Series Supervisor 1 Module is new and ideal for enterprise networks. It supports up to 1.44 Tbps capacity, 16 GB DRAM, and 10 GB Flash.
Out of Stock
General
- Model: C9400-SUP-1
- Condition: New
Performance & Capacity
- Centralized Wired Capacity: 1.44 Tbps
- Per-Slot Switching Capacity: 80 Gbps
- Total MAC Addresses: 64K
- Total IPv4 Routes: 112K
- IPv6 Routing Entries: 56K
- Forwarding Rate IPv4: 900 Mpps
- Forwarding Rate IPv6: 450 Mpps
Memory
- DRAM: 16 GB
- Flash: 10 GB
Physical
- Width: 37.90 cm
- Depth: 37.00 cm
- Height: 4.06 cm
- Weight: 4.5 kg
Environmental
- Operating Temperature: -5 to +45ºC
- Storage Temperature: -40 to +70ºC
- Relative Humidity: 10 to 95% noncondensing
- MTBF: 302,000 hours
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9400 1-Port Supervisor Module – New | C9400-SUP-1.
The maximum centralized wired capacity is 1.44 Tbps.
It can support up to 64K MAC addresses.
The forwarding rate for IPv4 traffic is 900 Mpps.
The operating temperature range is -5 to +45ºC.
The C9400-SUP-1 is equipped with 16 GB of DRAM.
The weight of the C9400-SUP-1 is 4.5 kg.
