Juniper MPC7E-MRATE 12-Port QSFP+/QSFP28 Line Card – Refurbished | MPC7E-MRATE
In Stock — Ready to Ship
1 units available
SKU
MPC7E-MRATE-REFURBISHED
MPN
MPC7E-MRATE
A$16,732
The Juniper MPC7E-MRATE is a refurbished line card ideal for data centers. It features 12x QSFP+/QSFP28 ports, 5 Tbps switching capacity, and supports up to 2M routes in FIB.
In Stock — Ready To Ship
Switching Capacity
5 Tbps
Packet Forwarding Rate
3200 Mpps
Forwarding Information Base (FIB)
Up to 2M routes
Routing Information Base (RIB)
Up to 6M routes
L3VPN Instances
Up to 32 per card
Weight
7.12 kg
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Juniper · MPC7E Series
MPC7E-MRATE 12-Port Line Card Refurbished
High-density multirate line card for versatile networking.
Overview
The Juniper MPC7E-MRATE is a high-performance line card designed for scalable networking solutions. Equipped with 12x QSFP+/QSFP28 ports, it supports extensive Layer 2 and Layer 3 functionalities. This card is capable of handling up to 2 million routes in the Forwarding Information Base (FIB) and 6 million in the Routing Information Base (RIB), making it suitable for demanding data center environments.
Key Features
- Port Configuration: 12x QSFP+/QSFP28 multirate ports.
- Switching Capacity: 5 Tbps.
- Forwarding Rate: 3200 Mpps.
- Routing Capacity: Up to 2 million routes in FIB.
- L3VPN Instances: Supports up to 32 instances per card.
- Operating Temperature: -5 °C to 50 °C.
- Weight: 7.12 kg.
- Jumbo Frame Support: Up to 9216 bytes.
Specifications
| General | |
|---|---|
| Device Type | Expansion module |
| Form Factor | Line card |
| Ports & PoE | |
| Ports | 12 x 100Gb Ethernet - QSFP28/QSFP+ |
| Performance & Capacity | |
| Switching Capacity | 5 Tbps |
| Packet Forwarding Rate | 3200 Mpps |
| Forwarding Information Base (FIB) | Up to 2M routes |
| Routing Information Base (RIB) | Up to 6M routes |
| L3VPN Instances | Up to 32 per card |
| Physical | |
| Weight | 7.12 kg |
| Environmental | |
| Operating Temperature | -5 °C to 50 °C |
| Storage Temperature | -40 °C to 70 °C |
| Humidity | 5% to 90% (non-condensing) |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Juniper MPC7E-MRATE 12-Port QSFP+/QSFP28 Line Card – Refurbished | MPC7E-MRATE.
The Juniper MPC7E-MRATE supports up to 32 L3VPN instances per card.
The switching capacity of the MPC7E-MRATE is 5 Tbps.
The FIB can support up to 2 million routes.
The weight of the MPC7E-MRATE is 7.12 kg.
The operating temperature range is -5 °C to 50 °C.
Out of the 12 ports, 4 support QSFP28.
