Cisco QSFP 40-Port 40GBASE-BiDi Transceiver Module – New | QSFP-40G-SR-BD
The Cisco QSFP-40G-SR-BD is a new bi-directional transceiver for high-performance networks. It supports 40 Gbps data rates, duplex LC connectivity, and a reach of up to 100 meters.
Out of Stock
Data Transfer Rate
40 Gbps
Max Transfer Distance
100 m on OM3, 150 m on OM4
Optical Wave Length
850 nm
Power Consumption
< 3.5 W
Width
0.7 in
Depth
2.9 in
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · QSFP Series
QSFP-40G-SR-BD 40-Port 40GBASE-BiDi Transceiver Module New
Optimised for high-density 40 Gigabit Ethernet connections.
Overview
The Cisco QSFP-40G-SR-BD is a cutting-edge 40GBASE-BiDi transceiver module designed for high-bandwidth optical links over duplex multimode fiber (MMF). It enables efficient upgrades from 10 Gigabit to 40 Gigabit Ethernet without requiring new fiber infrastructure. Ideal for data centers and HPC networks, it supports a reach of up to 100 meters on OM3 fiber.
Key Features
- Bi-Directional Transmission: Utilises two 20Gbps channels for simultaneous data transmission.
- Short-Reach Capability: Supports link lengths of up to 100 meters on OM3 and 150 meters on OM4 fibers.
- Plug-and-Play Installation: Designed for easy installation in existing network setups.
- Low Power Consumption: Efficient operation with minimal energy requirements.
- High Compatibility: Compliant with MSA QSFP specifications for broad platform support.
- Robust Environmental Range: Operates within 50°F to 158°F and 5% to 95% humidity.
Specifications
| General | |
|---|---|
| Device Type | QSFP+ transceiver module |
| Form Factor | Plug-in module |
| Color | Gray |
| Ports & PoE | |
| Interface Provided Qty | 1 x 40Gb Ethernet - LC multi-mode |
| Performance | |
| Data Transfer Rate | 40 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 492 ft (100 m on OM3, 150 m on OM4) |
| Power | |
| Power Consumption | < 3.5 W |
| Physical | |
| Width | 0.7 in |
| Depth | 2.9 in |
| Height | 0.5 in |
| Weight | 3.53 oz |
| Environmental | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 95% |
| Compliance | |
| Compliant Standards | FCC CFR21 Part 1040, GR-20-CORE, IEC 60825-1, RoHS |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco QSFP 40-Port 40GBASE-BiDi Transceiver Module – New | QSFP-40G-SR-BD.
The QSFP-40G-SR-BD supports a maximum distance of up to 100 meters on OM3 multimode fiber.
This transceiver uses a duplex LC connector for multimode fiber connections.
Yes, it allows for an upgrade from 10 Gigabit Ethernet to 40 Gigabit Ethernet without needing new fiber infrastructure.
The power consumption is less than 3.5 watts.
Yes, it complies with RoHS and other relevant standards.
The optical wavelength is 850 nm.
