Cisco Catalyst 3560X 48-Port Gigabit PoE+ IP Services Switch – New | WS-C3560X-48PF-E
The Cisco WS-C3560X-48PF-E is a new managed switch ideal for enterprise networks. It features 48 PoE+ ports, 1100W power supply, and 160 Gbps switching capacity.
Out of Stock
Device Type
Managed Switch - 48 ports - L3
Model
WS-C3560X-48PF-E
Series
Catalyst 3560X
Ports
48 x 10/100/1000 (PoE+)
PoE Budget
800 W
Switching Capacity
160 Gbps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 3560X Series
WS-C3560X-48PF-E 48-Port PoE+ Switch New
Designed for enterprise networks with advanced features.
Overview
The Cisco WS-C3560X-48PF-E is a high-performance managed switch designed for enterprise and medium-sized business networks. It features 48 PoE+ enabled 10/100/1000 Ethernet ports, allowing for efficient power and data connectivity. With a robust 1100W AC power supply and a compact 1 Rack Unit form factor, it ensures optimal space utilization and easy installation. The switch is equipped with advanced Layer 3 routing protocols and enhanced security features, making it suitable for demanding network environments.
Key Features
- PoE+ Capability: Supports 48 PoE+ ports for powering devices.
- Switching Capacity: Delivers 160 Gbps switching capacity.
- Forwarding Rate: Achieves a forwarding rate of 101.2 Mpps.
- Compact Design: Rack-mountable in a 1U form factor.
- Advanced Security: Features IP Services for enhanced security and management.
- High Availability: Supports redundancy and high availability features.
- Energy Efficient: Utilizes EnergyWise technology for energy management.
Specifications
| General | |
|---|---|
| Device Type | Managed Switch - 48 ports - L3 |
| Model | WS-C3560X-48PF-E |
| Series | Catalyst 3560X |
| Ports & PoE | |
| Ports | 48 x 10/100/1000 (PoE+) |
| PoE Budget | 800 W |
| Performance & Capacity | |
| Switching Capacity | 160 Gbps |
| Forwarding Rate | 101.2 Mpps |
| Power | |
| Power Supply | 1100 W AC |
| Max Power Consumption | 1700 W |
| Physical | |
| Width | 44.5 cm |
| Depth | 49.5 cm |
| Height | 4.45 cm |
| Weight | 7.5 kg |
| Environmental | |
| Operating Temperature | -5 °C to 40 °C |
| Storage Temperature | -40 °C to 70 °C |
| Humidity Range | 5 - 95% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, RoHS, UL 60950-1 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 3560X 48-Port Gigabit PoE+ IP Services Switch – New | WS-C3560X-48PF-E.
The PoE budget for this switch is 800 W, allowing it to power multiple devices.
The maximum switching capacity is 160 Gbps, ensuring high performance for data traffic.
This model features 48 PoE+ enabled 10/100/1000 Ethernet ports.
The switch has dimensions of 44.5 cm in width, 49.5 cm in depth, and 4.45 cm in height.
Yes, it is designed for enterprise and medium-sized business networks with advanced features.
It supports OSPF, BGP-4, EIGRP, and other advanced routing protocols.
