Cisco Catalyst 3650 48-Port UPOE LAN Base Switch – Refurbished | WS-C3650-12X48UR-L
In Stock — Ready to Ship
1 units available
SKU
WS-C3650-12X48UR-L-REFURBISHED
MPN
WS-C3650-12X48UR-L
A$4,832
The Cisco WS-C3650-12X48UR-L is a refurbished switch ideal for enterprise networks. It features 48 Ethernet ports, 8 x 10G uplinks, and a 1100W power supply.
In Stock — Ready To Ship
Device Type
Switch - 48 ports - L3 - managed - stackable
Enclosure Type
Desktop, rack-mountable 1U
Downlink Ports
12 x 100M/1G/2.5G/5G/10G UPOE, 36 x 10/100/1000 UPOE
Uplink Ports
8 x 10-Gigabit SFP+
PoE Budget
660 W
Switching Capacity
472 Gbps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 3650 Series
WS-C3650-12X48UR-L 48-Port UPOE Switch Refurbished
Designed for high-performance networking in enterprise environments.
Overview
The Cisco WS-C3650-12X48UR-L is a high-performance switch designed for demanding enterprise networking needs. It supports a robust configuration with 12 multi-gigabit UPOE downlink ports and 36 standard PoE+ ports, alongside eight 10-Gigabit uplink SFP+ ports. With a powerful 1100W AC power supply, this switch is optimized for high-density environments and offers flexible connectivity options.
Key Features
- Multi-Gigabit UPOE Ports: Supports up to 12 multi-gigabit Cisco UPOE ports for enhanced power delivery.
- High-Speed Uplinks: Equipped with eight 10-Gigabit SFP+ uplink ports for rapid data transfer.
- Power Management: Features a robust 1100W power supply for efficient operation.
- Stackable Design: Allows for simplified scaling and management in growing networks.
- Layer 2 and Layer 3 Support: Provides essential networking capabilities for diverse applications.
- High Performance: Offers switching capacity of 472 Gbps and forwarding performance of 351.19 Mpps.
- Environmental Resilience: Operates in temperatures from -5 °C to 45 °C with a humidity range of 5 - 96%.
- Extensive VLAN Support: Capable of supporting up to 4094 VLANs for network segmentation.
Specifications
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Desktop, rack-mountable 1U |
| Ports & PoE | |
| Downlink Ports | 12 x 100M/1G/2.5G/5G/10G UPOE, 36 x 10/100/1000 UPOE |
| Uplink Ports | 8 x 10-Gigabit SFP+ |
| PoE Budget | 660 W |
| Performance & Capacity | |
| Switching Capacity | 472 Gbps |
| Forwarding Rate | 351.19 Mpps |
| Memory | |
| RAM | 4 GB |
| Flash Memory | 4 GB |
| Layer & Routing | |
| Routing Protocols | RIP-1, RIP-2, static IP routing, RIPng |
| Stacking | |
| Stacking Bandwidth | 160 Gbps |
| Interfaces & Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x Stacking Module |
| Power | |
| Power Supply | 1100 Watt AC |
| Physical | |
| Width | 44.5 cm |
| Depth | 48.6 cm |
| Height | 4.4 cm |
| Weight | 8.08 kg |
| Environmental | |
| Operating Temperature | -5 °C to 45 °C |
| Storage Temperature | -40 °C to 70 °C |
| Operating Humidity | 5 - 96% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 3650 48-Port UPOE LAN Base Switch – Refurbished | WS-C3650-12X48UR-L.
The maximum PoE budget for the Cisco WS-C3650-12X48UR-L is 660W.
Yes, the WS-C3650-12X48UR-L supports stacking with a total of 1 expansion slot available.
This model features 8 x 10-Gigabit SFP+ uplink ports for high-speed connections.
The switching capacity of this switch is 472 Gbps.
The operating temperature range is from -5 °C to 45 °C.
The switch can support up to 4094 VLANs.
