What is the maximum data rate of the Cisco Catalyst 9130AXE-H?

The maximum data rate is up to 10 Gbps when using 160 MHz channels on the 5 GHz band.

What types of antennas can be used with the C9130AXE-H?

The C9130AXE-H supports external antennas with a Smart antenna connector.

Is the Cisco Catalyst 9130AXE-H suitable for IoT applications?

Yes, it is certified for IoT compatibility and supports BLE and Zigbee.

What is the operating temperature range for this access point?

The operating temperature range is from -4 °F to 122 °F.

How many spatial streams does the C9130AXE-H support?

It supports 4x4 MIMO technology, providing four spatial streams.

What encryption standards are supported by the C9130AXE-H?

It supports AES, TLS, WPA2, and WPA3 encryption standards.

NEW

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Cisco Catalyst 9130AX 4-Port Wi-Fi 6 Access Point – New | C9130AXE-H

Name: Cisco Catalyst 9130AX 4-Port Wi-Fi 6 Access Point – New | C9130AXE-H
Brand: Cisco
SKU: C9130AXE-H
Price: 1248 USD
Availability: InStock
Rating: 4.6 (5 reviews)

In Stock

1 units available

SKU

C9130AXE-H-NEW

MPN

C9130AXE-H

Be the first to review this product

$1,248

The Cisco Catalyst 9130AX is a new enterprise access point designed for high-density environments. Key specs include Wi-Fi 6 support, 4x4 MIMO, and multigigabit connectivity.

In Stock

General

Device Type: Wireless access point
Flash Memory: 1 GB
RAM: 2 GB

Ports & PoE

Ports: 1 x 1/2.5/5GBase-T (UPOE) - RJ-45, 1 x management - RJ-45, 1 x USB 2.0, 1 x antenna - DART-8

Performance & Capacity

Max Data Rate: 10 Gbps (160 MHz with 5 GHz)

Power

Power Over Ethernet: UPOE

Physical

Width: 9.2 in
Depth: 9.2 in
Height: 1.6 in
Weight: 3.77 lbs

Environmental

Min Operating Temperature: -4 °F
Max Operating Temperature: 122 °F
Humidity Range Operating: 10 - 90% (non-condensing)

Request a quote or add to cart — pricing available on enquiry for refurbished stock.

For international customers, please contact us for personalised support and assistance.

Request Quote / Enquire

180-Days Warranty

Secure Checkout

Free Delivery US

Dispatch in 1–2 Business Days

Add to Wish List Add to Compare

Description

Cisco · Catalyst 9130AX Series

C9130AXE-H 4-Port Wi-Fi 6 Access Point New

Ideal for high-density wireless environments.

Overview

The Cisco Catalyst 9130AX Series Access Points represent the next generation of enterprise access points, offering resilience, security, and intelligence. The C9130AXE-H model features external antennas and is equipped with Wi-Fi 6 technology, ensuring high performance in various deployment scenarios. With support for multigigabit connectivity and advanced features such as OFDMA and MU-MIMO, it is designed to meet the demands of modern wireless networks.

Key Features

Wi-Fi 6 Certified: Supports 802.11ax on both 2.4-GHz and 5-GHz bands.
4x4 MIMO Technology: Provides enhanced throughput and capacity.
Multigigabit Support: Interfaces include 1 x 1/2.5/5GBase-T (UPOE).
Integrated Security: Features AES, TLS, WPA2, and WPA3 encryption.
IoT Ready: Compatible with BLE and Zigbee protocols.
Environmental Resilience: Operates in temperatures from -4 °F to 122 °F.
Quality of Service (QoS): Ensures optimal performance for critical applications.

Specifications

General
Device Type	Wireless access point
Flash Memory	1 GB
RAM	2 GB
Ports & PoE
Ports	1 x 1/2.5/5GBase-T (UPOE) - RJ-45, 1 x management - RJ-45, 1 x USB 2.0, 1 x antenna - DART-8
Performance & Capacity
Max Data Rate	10 Gbps (160 MHz with 5 GHz)
Power
Power Over Ethernet (PoE)	UPOE
Physical
Width	9.2 in
Depth	9.2 in
Height	1.6 in
Weight	3.77 lbs
Environmental
Min Operating Temperature	-4 °F
Max Operating Temperature	122 °F
Humidity Range Operating	10 - 90% (non-condensing)
Compliance
Compliant Standards	IEEE 802.3, IEEE 802.11b/g/n/ac/ax, CISPR 24, EN 61000-3-2
