Cisco Catalyst 9300 24-Port UPOE Network Advantage Switch – Refurbished | C9300-24U-A

In Stock
1 units available
SKU
C9300-24U-A-REFURBISHED
MPN
C9300-24U-A
Be the first to review this product
$2,338
The Cisco Catalyst 9300 24-Port UPOE switch is refurbished and ideal for enterprise networks. It features 24 UPOE ports, 480 Gbps stacking bandwidth, and 830W PoE budget.
In Stock
Device Type Switch - 24 ports - L3 - managed - stackable
Enclosure Type Rack-mountable 1U
Ports 24 x 10/100/1000 (UPOE)
PoE Budget 830 W
Switching Capacity 128 Gbps
Forwarding Rate 154.76 Mpps

Request a quote or add to cart — pricing available on enquiry for refurbished stock.

For international customers, please contact us for personalised support and assistance.

Request Quote / Enquire
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Add to Wish List Add to Compare
Cisco · Catalyst 9300 Series
C9300-24U-A 24-Port UPOE Switch Refurbished
Designed for enterprise-class networking needs.
Overview
The Cisco Catalyst 9300 Series Switches are the leading stackable enterprise switching platform designed for security, IoT, and cloud applications. The C9300-24U-A model is equipped with an x86 CPU architecture and expanded memory, enabling it to manage high-speed data, voice, and video services efficiently. This switch supports advanced features like Cisco StackWise technology and is built for future-readiness.
Key Features
  • UPOE Ports: 24 x 10/100/1000 UPOE ports for versatile connectivity.
  • Stacking Bandwidth: Industry-leading 480 Gbps stacking bandwidth.
  • PoE Budget: 830W PoE budget for powering devices.
  • Switching Capacity: 128 Gbps switching capacity for high performance.
  • Memory: 8 GB RAM and 16 GB Flash for robust operations.
  • Environmental Support: Operating temperature range from 23°F to 113°F.
  • Layer 2 and Layer 3 Support: Comprehensive capabilities for enterprise networking.
  • Hot-Swappable Components: Supports hot-swappable power supplies and fans.
Specifications
General
Device TypeSwitch - 24 ports - L3 - managed - stackable
Enclosure TypeRack-mountable 1U
Ports & PoE
Ports24 x 10/100/1000 (UPOE)
PoE Budget830 W
Performance & Capacity
Switching Capacity128 Gbps
Forwarding Rate154.76 Mpps
Stacking Bandwidth480 Gbps
Memory
RAM8 GB
Flash Memory16 GB
Layer & Routing
Routing ProtocolsOSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, MSDP, policy-based routing (PBR), RIPng
Stacking
Stacking TechnologyCisco StackWise-480
Interfaces & Connectivity
Expansion Slots1 (total) / 1 (free)
Power
Power SupplyInternal power supply - hot-plug
Power RedundancyOptional
Physical
Width17.5 in
Depth17.5 in
Height1.73 in
Weight16.33 lbs
Environmental
Min Operating Temperature23 °F
Max Operating Temperature113 °F
Humidity Range Operating5 - 90% (non-condensing)
Min Storage Temperature-40 °F
Max Storage Temperature158 °F
Compliance
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Documents

Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.

Reviews
Write Your Own Review
You're reviewing:Cisco Catalyst 9300 24-Port UPOE Network Advantage Switch – Refurbished | C9300-24U-A
Your Rating
FAQ

Common questions about the Cisco Catalyst 9300 24-Port UPOE Network Advantage Switch – Refurbished | C9300-24U-A.

The C9300-24U-A supports stacking of up to 8 switches.
The total PoE budget for the C9300-24U-A is 830W.
Yes, the C9300-24U-A supports modular uplinks with options for 1G, 10G, or 25G.
The switch supports OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, and more.
The forwarding rate is 154.76 Mpps.
The C9300-24U-A weighs approximately 16.33 lbs.
