Cisco Catalyst 9300X 12-Port 25G Network Advantage Switch – New | C9300X-12Y-A
In Stock — Ready to Ship
1 units available
SKU
C9300X-12Y-A-NEW
MPN
C9300X-12Y-A
$10,185
The Cisco Catalyst 9300X is a new L3 switch designed for enterprise branches and campuses. It features 12 x 25G SFP28 ports, 1000 Gbps switching capacity, and advanced security features.
In Stock — Ready To Ship
Device Type
Switch - 12 ports - L3 - managed - stackable
Enclosure Type
Rack-mountable 1U
Ports
12 x 25G SFP28
Switching Capacity
1000 Gbps
Forwarding Rate
744.04 Mpps
MAC Address Table Size
32000 entries
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300X-12Y-A 12-Port 25G Switch New
Ideal for enterprise branches with high-density connectivity.
Overview
The Cisco Catalyst 9300X is a leading stackable enterprise switch designed for security, IoT, mobility, and cloud applications. It is powered by Cisco's IOS XE software and is optimized for high-density Wi-Fi environments. This model supports flexible network architectures and extensive programmability, making it suitable for small to medium-sized businesses and enterprise branches.
Key Features
- High Port Density: 12 ports of 25G/10G/1G SFP28 provide versatile connectivity options.
- Advanced Security: Features like secure boot, Trustworthy Systems, and MACsec enhance network security.
- High Performance: Offers a switching capacity of 1000 Gbps and a forwarding rate of 744.04 Mpps.
- Stacking Capability: Supports Cisco StackWise technology for high-density stacking.
- Energy Efficiency: Supports Energy Efficient Ethernet (EEE) for reduced power consumption.
- Robust Management: Remote management via SNMP, CLI, NETCONF, and RESTCONF protocols.
Specifications
| General | |
|---|---|
| Device Type | Switch - 12 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable 1U |
| Ports & PoE | |
| Ports | 12 x 25G SFP28 |
| Performance & Capacity | |
| Switching Capacity | 1000 Gbps |
| Forwarding Rate | 744.04 Mpps |
| MAC Address Table Size | 32000 entries |
| VLAN IDs | 4094 |
| Memory | |
| RAM | 16 GB |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM |
| Stacking | |
| Stacking Bandwidth | 2000 Gbps |
| Interfaces & Connectivity | |
| Uplink Ports | Modular |
| Power | |
| Power Device | Internal power supply |
| Power Provided | 715 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Physical | |
| Width | 17.5 in |
| Depth | 16.1 in |
| Height | 1.73 in |
| Weight | 15.0 Pounds |
| Environmental | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, RoHS |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300X 12-Port 25G Network Advantage Switch – New | C9300X-12Y-A.
The maximum switching capacity is 1000 Gbps.
It has 12 ports of 25G SFP28.
The forwarding rate is 744.04 Mpps.
Yes, it supports Cisco StackWise technology for high-density stacking.
It operates between 23 °F and 113 °F with a humidity range of 5 - 90%.
It uses an internal power supply providing 715 Watts.
