Cisco Nexus 9300 32-Port 40G QSFP+ Managed Switch – Refurbished | N9K-C9332PQ
In Stock — Ready to Ship
1 units available
SKU
N9K-C9332PQ-REFURBISHED
MPN
N9K-C9332PQ
$429
The Cisco N9K-C9332PQ Nexus 9300 is a refurbished switch ideal for data centers. It features 32 ports of 40G QSFP+, 2.56 Tbps bandwidth, and low-latency performance.
In Stock — Ready To Ship
General
- Device Type: Switch - 32 ports - L3 - Managed
- Enclosure Type: Desktop, rack-mountable 1U
Ports & PoE
- Ports: 26 x 40Gbit QSFP+ (breakout compatible) + 6 x 40Gbit QSFP+ (uplink)
Performance & Capacity
- Bandwidth: 2.56 Tbps
- Longest prefix match (LPM) entries (IPv4): 16000
- Host table entries (IPv4): 208000
- IPv4 routes (Multicast): 32000
- Virtual interfaces (VLANs): 4096
- Equal-Cost Multipathing (ECMP) ways: 64
- Multiple Spanning Tree Protocol instances: 64
- Rapid Per-VLAN Spanning Tree Plus instances: 507
- Virtual Routing and Forwarding (VRF) entries: 1000
- IGMP snooping entries: 32000
- ACL entries (ingress): 4000
- ACL entries (egress): 1000
Power
- Power Device: Internal power supply - hot-plug
- Power Redundancy: Yes
Physical
- Width: 43.9 cm
- Depth: 57.1 cm
- Height: 4.4 cm
- Weight: 10.0 kg
Environmental
- Humidity Range Operating: 5 - 95% (non-condensing)
- Max Operating Temperature: 40 °C
- Max Storage Temperature: 70 °C
- Min Operating Temperature: 0 °C
- Min Storage Temperature: -40 °C
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Nexus 9300 Series
N9K-C9332PQ 32-Port 40G QSFP+ Switch Refurbished
High-density switching for advanced data center applications
Overview
The Cisco Nexus 9300 N9K-C9332PQ is a high-performance switch designed for top-of-rack and middle-of-row deployment in data centers. It supports enterprise applications and cloud computing environments with its Layer 2 and 3 nonblocking architecture. With a robust internal bandwidth of up to 2.56 terabits per second, it is engineered for low-latency performance and high availability.
Key Features
- High Density: 32 ports of 40G QSFP+ for superior port density.
- Flexible Configuration: Supports breakout cables allowing for 128 10G ports.
- Low Latency: Offers low-latency switching, suitable for high-performance applications.
- Scalable: Designed to scale for growing data center environments.
- Energy Efficient: Built with power efficiency in mind, reducing overall power consumption.
- Operational Simplicity: Unified under the Cisco Nexus Operating System (NX-OS) for simplified management.
- Advanced Security: Features such as Cisco TrustSec and support for Cisco ACI.
- High Availability: Redundant power supplies and fans for increased reliability and uptime.
Specifications
| General | |
|---|---|
| Device Type | Switch - 32 ports - L3 - Managed |
| Enclosure Type | Desktop, rack-mountable 1U |
| Ports & PoE | |
| Ports | 26 x 40Gbit QSFP+ (breakout compatible) + 6 x 40Gbit QSFP+ (uplink) |
| Performance & Capacity | |
| Bandwidth | 2.56 Tbps |
| Longest prefix match (LPM) entries (IPv4) | 16000 |
| Host table entries (IPv4) | 208000 |
| IPv4 routes (Multicast) | 32000 |
| Virtual interfaces (VLANs) | 4096 |
| Equal-Cost Multipathing (ECMP) ways | 64 |
| Multiple Spanning Tree Protocol instances | 64 |
| Rapid Per-VLAN Spanning Tree Plus instances | 507 |
| Virtual Routing and Forwarding (VRF) entries | 1000 |
| IGMP snooping entries | 32000 |
| ACL entries (ingress) | 4000 |
| ACL entries (egress) | 1000 |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Power Redundancy | Yes |
| Physical | |
| Width | 43.9 cm |
| Depth | 57.1 cm |
| Height | 4.4 cm |
| Weight | 10.0 kg |
| Environmental | |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
| Compliance | |
| Compliant Standards | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, GB 4943, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN22 Class A, EN 300386 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Nexus 9300 32-Port 40G QSFP+ Managed Switch – Refurbished | N9K-C9332PQ.
The maximum bandwidth of the N9K-C9332PQ is 2.56 Tbps.
The N9K-C9332PQ has 32 ports of 40G QSFP+.
The operating temperature range for the N9K-C9332PQ is 0 °C to 40 °C.
Yes, the N9K-C9332PQ supports redundant power supplies.
The weight of the N9K-C9332PQ is 10.0 kg.
The maximum storage temperature for the N9K-C9332PQ is 70 °C.
