Cisco QSFP-40G-CSR-S 40GBASE-CSR QSFP Module for Duplex MMF – Refurbished | QSFP-40G-CSR-S
In Stock — Ready to Ship
1 units available
SKU
QSFP-40G-CSR-S-REFURBISHED
MPN
QSFP-40G-CSR-S
$818
The Cisco QSFP-40G-CSR-S is a refurbished optical transceiver designed for duplex multimode fiber networks. It supports link lengths up to 400 meters on OM4 fiber and delivers 40 Gbps data rates.
In Stock — Ready To Ship
Device Type
QSFP+ transceiver module
Form Factor
Plug-in module
Color
Orange
Interfaces
1 x Ethernet 40GBASE-SR - LC multi-mode
Data Rate
40 Gbps
Optical Wave Length
850 nm
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · QSFP-40G-CSR-S
QSFP-40G-CSR-S 40GBASE-CSR QSFP Module for Duplex MMF Refurbished
High-performance optical transceiver for high-bandwidth networks.
Overview
The Cisco QSFP-40G-CSR-S is a pluggable optical transceiver that utilizes a duplex LC connector interface for connectivity over multimode fiber (MMF). It is designed to support link lengths of 300 meters on OM3 and up to 400 meters on OM4 fibers, making it ideal for high-bandwidth applications in data centers and advanced networking environments. This module operates at four wavelengths and is engineered for low power consumption and excellent performance.
Key Features
- High Data Rate: Supports 40 Gbps data transfer rates.
- Long Distance Support: Operates over distances up to 400 meters on OM4 multimode fiber.
- Low Power Consumption: Designed for energy efficiency.
- Hot-swappable: Can be replaced without powering down the system.
- Digital Optical Monitoring (DOM): Provides real-time monitoring of the optical link.
- Compact Form Factor: QSFP design allows for high-density deployments.
Specifications
| General | |
|---|---|
| Device Type | QSFP+ transceiver module |
| Form Factor | Plug-in module |
| Color | Orange |
| Ports & PoE | |
| Interfaces | 1 x Ethernet 40GBASE-SR - LC multi-mode |
| Performance | |
| Data Rate | 40 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 400m on OM4 |
| Power | |
| Power Consumption | Low |
| Physical | |
| Width | 0.7 in |
| Depth | 2.9 in |
| Height | 0.5 in |
| Weight | 3.53 oz |
| Environmental | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Compliance | |
| Compliant Standards | Laser Class 1, ELV, RoHS, IEC 60825-1, GR-326-CORE, MSA, GR-20-CORE, GR-1435-CORE, OM4, OM3 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco QSFP-40G-CSR-S 40GBASE-CSR QSFP Module for Duplex MMF – Refurbished | QSFP-40G-CSR-S.
The QSFP-40G-CSR-S supports link lengths of up to 400 meters on OM4 multimode fiber.
Yes, it allows for the reuse of existing 10 gigabit duplex MMF infrastructure while migrating to 40 Gigabit Ethernet.
Yes, the QSFP-40G-CSR-S is designed to be hot-swappable, allowing for easy replacement without system downtime.
It uses a standard LC connector interface for multimode fiber connections.
Yes, it supports Digital Optical Monitoring (DOM) for real-time monitoring of the optical link.
The operating temperature range is from 32 °F to 158 °F.
