Cisco Catalyst 3560X 48-Port PoE+ IP Base Switch – Refurbished | WS-C3560X-48PF-S
In Stock — Ready to Ship
2 units available
SKU
WS-C3560X-48PF-S-REFURBISHED
MPN
WS-C3560X-48PF-S
$270
The Cisco Catalyst 3560X is a refurbished 48-port switch ideal for medium to large enterprises. It features PoE+ support, 1100W power supply, and Layer 2/3 capabilities.
In Stock — Ready To Ship
General
- Device Type: Managed Switch
- Enclosure Type: Rack-mountable 1U
Ports & PoE
- Ports: 48 x 10/100/1000 (PoE+)
- Power Over Ethernet (PoE): PoE+ (up to 30W per port)
- PoE Budget: 800W
Performance & Capacity
- Switching Fabric Bandwidth: 160 Gbps
- Forwarding Rate: 101.2 Mpps
- VLANs Supported: 1005
Memory
- RAM: 256 MB
- Flash Memory: 128 MB
Layer & Routing
- Routing Protocols: RIP-1, RIP-2, HSRP, static IP routing, RIPng
Power
- Power Supply: Internal 1100W AC
- Voltage Required: AC 120/230 V (50/60 Hz)
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Catalyst 3560X Series
WS-C3560X-48PF-S 48-Port PoE+ Switch Refurbished
Ideal for campus and branch deployments with robust features.
Overview
The Cisco Catalyst 3560X is an enterprise-class standalone switch designed for high availability and security. It supports advanced Layer 2 and basic Layer 3 routing features, making it suitable for diverse network deployments. With PoE+ capabilities, it enhances productivity by powering devices like IP phones and wireless access points directly through the network cable.
Key Features
- 48 PoE+ Ports: Supports 10/100/1000 Ethernet connections.
- 1100W Power Supply: Ensures reliable power delivery for connected devices.
- Layer 2/3 Functionality: Provides advanced switching and basic routing capabilities.
- Energy Efficient: Features Energy Efficient Ethernet (EEE) for reduced power consumption.
- High Availability: Supports features like Rapid Spanning Tree Protocol (RSTP) for network resilience.
- Robust Security: Includes support for IEEE 802.1x and Cisco TrustSec for secure access control.
- Scalability: Compatible with Cisco StackWise technology for enhanced scalability.
Specifications
| General | |
|---|---|
| Device Type | Managed Switch |
| Enclosure Type | Rack-mountable 1U |
| Ports & PoE | |
| Ports | 48 x 10/100/1000 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ (up to 30W per port) |
| PoE Budget | 800W |
| Performance & Capacity | |
| Switching Fabric Bandwidth | 160 Gbps |
| Forwarding Rate | 101.2 Mpps |
| VLANs Supported | 1005 |
| Memory | |
| RAM | 256 MB |
| Flash Memory | 128 MB |
| Layer & Routing | |
| Routing Protocols | RIP-1, RIP-2, HSRP, static IP routing, RIPng |
| Power | |
| Power Supply | Internal 1100W AC |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Physical | |
| Width | 44.5 cm |
| Depth | 49.5 cm |
| Height | 4.5 cm |
| Weight | 7.5 kg |
| Environmental | |
| Operating Temperature | -5 to 70 °C |
| Humidity Range | 5 - 95% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, RoHS, UL 60950-1 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 3560X 48-Port PoE+ IP Base Switch – Refurbished | WS-C3560X-48PF-S.
The maximum PoE budget for the WS-C3560X-48PF-S is 800W.
The WS-C3560X-48PF-S can support up to 1005 VLANs.
The dimensions are 44.5 cm in width, 49.5 cm in depth, and 4.5 cm in height.
The switching capacity of the WS-C3560X-48PF-S is 160 Gbps.
Yes, the WS-C3560X-48PF-S offers basic Layer 3 routing capabilities.
It supports RIP-1, RIP-2, HSRP, static IP routing, and RIPng.
No documents available for this product yet.
