Cisco Catalyst 9200L 24-Port Gigabit Data 4x10G Network Advantage Switch – New | C9200L-24T-4X-A
In Stock — Ready to Ship
1 units available
SKU
C9200L-24T-4X-A-NEW
MPN
C9200L-24T-4X-A
A$5,535
The Cisco Catalyst 9200L 24-port switch is new and ideal for enterprise networks. It features 24 gigabit Ethernet ports, 4x 10G uplinks, and advanced Layer 2/3 capabilities.
In Stock — Ready To Ship
Device Type
Switch - 24 ports - L3 - stackable
Enclosure Type
Rack-mountable
Gigabit Ethernet Ports
24 x 10/100/1000BASE-T
Uplink Ports
4 x 10G SFP+
Switching Capacity
128 Gbps
Forwarding Rate
190.4 Mpps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9200 Series
C9200L-24T-4X-A 24-Port Gigabit Switch New
Optimised for enterprise networks with advanced security features.
Overview
The Cisco Catalyst 9200L 24-port switch is designed for mid-sized and enterprise networks, providing high-speed data connectivity and advanced Layer 2/3 features. Built on Cisco's intent-based networking architecture, it supports robust security, automation, and segmentation capabilities. This switch is ideal for environments requiring reliable performance and scalability.
Key Features
- Gigabit Ethernet Ports: 24 x 10/100/1000BASE-T ports for high-speed data transfer.
- Uplink Configuration: 4 x 10G SFP+ uplink ports for enhanced network performance.
- Switching Capacity: 128 Gbps to handle high data loads efficiently.
- Forwarding Rate: 190.4 Mpps for fast packet processing.
- Layer 3 Routing: Supports OSPF, EIGRP, RIP, and more for advanced routing capabilities.
- Power Over Ethernet: Supports up to 48 ports of full PoE+ capability.
- Advanced Security: Features AES-128 MACsec encryption and policy-based segmentation.
- Management Protocols: SNMP, CLI, NETCONF, and RESTCONF for remote management.
Specifications
| General | |
|---|---|
| Device Type | Switch - 24 ports - L3 - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Gigabit Ethernet Ports | 24 x 10/100/1000BASE-T |
| Uplink Ports | 4 x 10G SFP+ |
| Performance & Capacity | |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 190.4 Mpps |
| MAC Address Table Size | 16,000 entries |
| IPv4 Routes | 11,000 (8,000 direct, 3,000 indirect) |
| IPv4 Routing Entries | 3,000 |
| IPv6 Routing Entries | 1,500 |
| VLANs Supported | 1024 |
| Memory | |
| RAM | 2 GB |
| Flash Memory | 4 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, VRRP, PIM-SM |
| Stacking | |
| Stacking Bandwidth | 80 Gbps |
| Interfaces & Connectivity | |
| Management Interface | 1 x management (LAN) RJ-45 |
| Console Interface | 1 x console RJ-45 |
| Power | |
| Power Supply | Internal power supply - hot-plug |
| Max Supported Qty | 2 |
| Physical | |
| Width | 17.5 in (44.5 cm) |
| Depth | 1.7 in (4.4 cm) |
| Height | 11.3 in (28.8 cm) |
| Weight | 11.02 lbs (5.0 kg) |
| Environmental | |
| Operating Humidity | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Compliance | |
| MTBF | 525,990 hours |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9200L 24-Port Gigabit Data 4x10G Network Advantage Switch – New | C9200L-24T-4X-A.
The C9200L-24T-4X-A supports up to 1024 VLANs.
The switching capacity is 128 Gbps.
Yes, it supports Layer 3 routing protocols including OSPF and EIGRP.
It can handle up to 16,000 MAC address entries.
The forwarding rate is 190.4 Mpps.
Yes, it supports up to 48 ports of full Power over Ethernet Plus (PoE+).
