Cisco Catalyst 9300 48-Port 2.5G UPOE Network Essentials Switch – Refurbished | C9300-48UXM-E
In Stock — Ready to Ship
1 units available
SKU
C9300-48UXM-E-REFURBISHED
MPN
C9300-48UXM-E
A$3,042
The Cisco Catalyst 9300-48UXM-E is a refurbished 48-port switch ideal for enterprises. It features 36 x 2.5GBase-T ports, 12 multi-gigabit ports, and a PoE budget of 490W.
In Stock — Ready To Ship
General
- Device Type: Switch - 48 ports - L3 - managed - stackable
- Enclosure Type: Rack-mountable 1U
Ports & PoE
- Port Configuration: 36 x 2.5GBase-T (UPOE) + 12 x 100/1000/2.5G/5G/10G (UPOE)
- Power Over Ethernet (PoE): UPOE
- PoE Budget: 490 W
Performance & Capacity
- Switching Capacity: 580 Gbps
- Forwarding Rate: 431.54 Mpps
- MAC Address Table Size: 32000 entries
- Jumbo Frame Support: 9198 bytes
Memory
- RAM: 8 GB
- Flash Memory: 16 GB
Layer & Routing
- Routing Protocols: OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
Stacking
- Stacking Bandwidth: 480 Gbps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300-48UXM-E 48-Port 2.5G UPOE Switch Refurbished
High-performance switch designed for modern enterprise networks.
Overview
The Cisco Catalyst 9300-48UXM-E is a robust enterprise-level switch built for scalability and performance. It is part of the Catalyst 9300 series, designed to support advanced networking features and seamless connectivity. This switch is ideal for complex network environments, providing high-speed data transfer and efficient power delivery through UPOE technology.
Key Features
- 48 Ports: Includes 36 x 2.5GBase-T and 12 x 100/1000/2.5G/5G/10G UPOE ports.
- PoE Budget: Supports a total power budget of 490W for connected devices.
- Switching Capacity: Delivers a switching capacity of 580 Gbps.
- Stacking Bandwidth: Offers up to 480 Gbps with StackWise-480 technology.
- Memory: Equipped with 8 GB RAM and 16 GB Flash memory.
- Management Protocols: Supports SNMP, RMON, CLI, NETCONF, and RESTCONF.
- Environmental Resilience: Operates in temperatures from 23°F to 113°F with 5-90% humidity.
- Compliance: Meets various international standards including IEEE and RoHS.
Specifications
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable 1U |
| Ports & PoE | |
| Port Configuration | 36 x 2.5GBase-T (UPOE) + 12 x 100/1000/2.5G/5G/10G (UPOE) |
| Power Over Ethernet (PoE) | UPOE |
| PoE Budget | 490 W |
| Performance & Capacity | |
| Switching Capacity | 580 Gbps |
| Forwarding Rate | 431.54 Mpps |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9198 bytes |
| Memory | |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng |
| Stacking | |
| Stacking Bandwidth | 480 Gbps |
| Interfaces & Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) |
| USB Ports | 1 x USB 2.0 |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Power Provided | 1100 W |
| Physical | |
| Width | 17.5 in |
| Depth | 18.5 in |
| Height | 1.7 in |
| Weight | 20.59 lbs |
| Environmental | |
| Operating Temperature | 23°F to 113°F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, RoHS, and others. |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300 48-Port 2.5G UPOE Network Essentials Switch – Refurbished | C9300-48UXM-E.
The PoE budget for the Cisco Catalyst 9300-48UXM-E is 490W.
The switch features 48 ports, including 36 x 2.5GBase-T and 12 multi-gigabit ports.
The Cisco Catalyst 9300-48UXM-E has a switching capacity of 580 Gbps.
Yes, it supports StackWise-480 technology with a stacking bandwidth of 480 Gbps.
It supports various routing protocols including OSPF, IS-IS, and RIP.
The switch weighs 20.59 lbs.
