Cisco Catalyst 9300 48-Port PoE+ Network Essentials Switch – Refurbished | C9300L-48P-4G-E
In Stock — Ready to Ship
1 units available
SKU
C9300L-48P-4G-E-REFURBISHED
MPN
C9300L-48P-4G-E
A$3,225
The Cisco Catalyst 9300L-48P-4G-E is a refurbished switch ideal for medium to large enterprises. It features 48 PoE+ ports, 4x1G uplinks, and a 505W PoE budget.
In Stock — Ready To Ship
Device Type
Switch - 48 ports - L3 - stackable
Enclosure Type
Rack-mountable
Ports
48 x 10/100/1000 (PoE+)
Uplink Interfaces
4 x 1G SFP+
Power Over Ethernet (PoE)
PoE+ (505W)
Switching Capacity
104 Gbps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300L-48P-4G-E 48-Port PoE+ Switch Refurbished
Designed for secure and efficient network management.
Overview
The Cisco Catalyst 9300 Series switches are Cisco's premier stackable enterprise switching platform, optimized for security, IoT, mobility, and cloud environments. This model, C9300L-48P-4G-E, integrates advanced features and a robust architecture, forming the backbone of Software-Defined Access (SD-Access). With 48 PoE+ ports and 4x1G uplinks, it ensures extensive connectivity and energy-efficient power delivery for various devices.
Key Features
- 48 PoE+ Ports: Supports Power over Ethernet Plus with a budget of 505W.
- 4x1G Uplinks: Fixed configuration for high-speed connectivity.
- Stackable Design: Supports Cisco StackWise technology for flexible deployment.
- High Switching Capacity: 104 Gbps switching capacity and 424 Gbps with stacking.
- Advanced Security: Features like MACsec support and 802.1x authentication.
- Robust Performance: Forwarding rate of 77.38 Mpps and 315.48 Mpps with stacking.
- Environmental Resilience: Operating humidity range of 5 - 90% (non-condensing).
- Extensive VLAN Support: Up to 4094 VLANs and 1000 switched virtual interfaces.
Specifications
| General | |
|---|---|
| Device Type | Switch - 48 ports - L3 - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Ports | 48 x 10/100/1000 (PoE+) |
| Uplink Interfaces | 4 x 1G SFP+ |
| Power Over Ethernet (PoE) | PoE+ (505W) |
| Performance & Capacity | |
| Switching Capacity | 104 Gbps |
| Switching Capacity with Stacking | 424 Gbps |
| Forwarding Rate | 77.38 Mpps |
| Forwarding Rate with Stacking | 315.48 Mpps |
| Memory | |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Stacking | |
| Stacking Bandwidth | 320 Gbps |
| Interfaces & Connectivity | |
| MAC Address Table Size | 32000 entries |
| VLANs Supported | 4094 |
| Switched Virtual Interfaces (SVIs) | 1000 |
| Power | |
| Power Consumption | 715W |
| Physical | |
| Width | 17.5 in |
| Depth | 1.73 in |
| Height | 16.1 in |
| Weight | 7.03 kg |
| Environmental | |
| Operating Humidity | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3bz |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300 48-Port PoE+ Network Essentials Switch – Refurbished | C9300L-48P-4G-E.
The maximum PoE budget for the C9300L-48P-4G-E is 505W.
The switch supports up to 4094 VLANs.
The forwarding rate is 77.38 Mpps, and 315.48 Mpps with stacking.
Yes, it supports Cisco StackWise technology with a stacking bandwidth of 320 Gbps.
It supports OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, and others.
The dimensions are 17.5 in width, 1.73 in height, and 16.1 in depth.
