Cisco Catalyst 9300 24-Port mGig UPOE+ Network Essentials Switch – Refurbished | C9300X-24HX-E

Name: Cisco Catalyst 9300 24-Port mGig UPOE+ Network Essentials Switch – Refurbished | C9300X-24HX-E
Brand: Cisco
SKU: C9300X-24HX-E
Availability: BackOrder
Rating: 4.2 (5 reviews)

Out of stock

SKU

C9300X-24HX-E-REFURBISHED

MPN

C9300X-24HX-E

Be the first to review this product

A$0

The Cisco Catalyst 9300 24-Port mGig UPOE+ switch is refurbished and ideal for enterprise networks. It features 24 ports, 1835W PoE budget, and 880 Gbps switching capacity.

Out of Stock

Device Type Switch - 24 ports - L3 - managed - stackable

Enclosure Type Rack-mountable

Ports 24 x 100/1000/2.5G/5G/10GBase-T (UPOE+)

PoE Budget 1835 W

Switching Capacity 880 Gbps

Switching Capacity with Stacking 1880 Gbps

Request a quote or add to cart — pricing available on enquiry for refurbished stock.

For international customers, please contact us for personalised support and assistance.

Request Quote / Enquire

180-Days Warranty

Secure Checkout

Free Delivery AU

Dispatch in 1–2 Business Days

Add to Wish List Add to Compare

Description

Cisco · Catalyst 9300 Series

C9300X-24HX-E 24-Port mGig UPOE+ Switch Refurbished

Designed for high-density environments with advanced management capabilities.

Overview

The Cisco Catalyst 9300 Series switches are the leading stackable enterprise access switching platform designed for security, IoT, mobility, and cloud applications. Built on an x86 CPU architecture, these switches support advanced network management and are optimized for high-density Wi-Fi 6 environments. With the ability to host containers and run applications natively, they provide a robust solution for modern enterprise needs.

Key Features

High-Density Ports: 24 x 100/1000/2.5G/5G/10GBase-T UPOE+ ports.
Power Over Ethernet: 1835W PoE budget for powering devices.
Switching Capacity: 880 Gbps with stacking capability of 1880 Gbps.
Advanced Security: Supports 256-bit AES encryption and various routing protocols.
Memory: 16 GB RAM and 16 GB Flash for efficient operation.
Environmental Resilience: Operates in temperatures from 23°F to 113°F.
Rack-Mountable: Standard 1U form factor for easy installation.
Remote Management: Supports NETCONF, RESTCONF, and SNMP protocols.

Specifications

General
Device Type	Switch - 24 ports - L3 - managed - stackable
Enclosure Type	Rack-mountable
Ports & PoE
Ports	24 x 100/1000/2.5G/5G/10GBase-T (UPOE+)
PoE Budget	1835 W
Performance & Capacity
Switching Capacity	880 Gbps
Switching Capacity with Stacking	1880 Gbps
Forwarding Rate	327.38 Mpps
Forwarding Rate with Stacking	1398.8 Mpps
Memory
RAM	16 GB
Flash Memory	16 GB
Layer & Routing
Routing Protocols	MSTP, static IP routing, RIP-1, RIP-2, RIPng, PIM-SM, PIM-SSM, GRE, policy-based routing (PBR), STP, VRRP, LISP
Stacking
Stacking Bandwidth	1 TB with Stackwise-1T
Interfaces & Connectivity
Expansion Slots	1 (total) / 1 (free)
USB Ports	1 x USB 2.0
Power
Power Device	Internal power supply - hot-plug
Power Provided	1100 Watt
Physical
Width	17.5 in
Depth	20.6 in
Height	1.7 in
Weight	13.78 lbs
Environmental
Operating Humidity Range	5 - 90% (non-condensing)
Max Operating Temperature	113 °F
Min Operating Temperature	23 °F
Max Storage Temperature	158 °F
Min Storage Temperature	-40 °F
Compliance
Compliant Standards	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, FCC CFR47 Part 15, EN 300 386 V1.6.1, EN 55032 Class A, CISPR 32 Class A, EN 61000-3-2, EN 61000-3-3, ICES-003 Class A, TCVN 7189 Class A, V-3 Class A, CISPR 35, EN 300 386, EN 55035, TCVN 7317, V-2/2015.04, V-3/2015.04, CNS 13438, KN32, KN35, RoHS
