Cisco Catalyst 9500 40-Port 10Gig Network Advantage Switch – Refurbished | C9500-40X-A
In Stock — Ready to Ship
1 units available
SKU
C9500-40X-A-REFURBISHED
MPN
C9500-40X-A
A$4,121
The Cisco Catalyst 9500 is a refurbished 40-port 10Gig switch ideal for enterprise networks. It features 480 Gbps switching capacity, 720 Mpps forwarding rate, and 40 x 10G SFP+ ports.
In Stock — Ready To Ship
Device Type
Switch - 40 ports - L3 - Managed
Enclosure Type
Rack-mountable 1U
Ports
40 x 10G SFP+
Power Over Ethernet
UPOE
Switching Capacity
480 Gbps
Forwarding Rate
720 Mpps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery AU
Dispatch in 1–2 Business Days
Cisco · Catalyst 9500 Series
C9500-40X-A 40-Port 10Gig Switch Refurbished
High-performance switch for enterprise networks.
Overview
The Cisco Catalyst 9500 Series Switches represent the next generation of enterprise-class core and aggregation layer switches. Built on an x86 CPU, this series is designed for programmability and serviceability, making it ideal for security, IoT, and cloud applications. The C9500-40X-A model is specifically tailored for enterprise campuses, offering robust performance and advanced features.
Key Features
- Switching Capacity: Up to 480 Gbps full duplex.
- Forwarding Rate: 720 Mpps for high-speed data processing.
- Ports: 40 x 10G SFP+ interfaces for flexible connectivity.
- Power Over Ethernet: Supports UPOE for enhanced power delivery.
- Environmental Tolerance: Operates in temperatures from 0°C to 40°C.
- Compliance Standards: Meets IEEE 802.3 and other industry standards.
- Memory: Equipped with 16 GB RAM and 16 GB Flash memory.
- Management Protocols: Supports SNMP, RMON, NETCONF, and RESTCONF.
Specifications
| General | |
|---|---|
| Device Type | Switch - 40 ports - L3 - Managed |
| Enclosure Type | Rack-mountable 1U |
| Ports & PoE | |
| Ports | 40 x 10G SFP+ |
| Power Over Ethernet | UPOE |
| Performance & Capacity | |
| Switching Capacity | 480 Gbps |
| Forwarding Rate | 720 Mpps |
| MAC Address Table Size | 64K entries |
| VLAN IDs | 4000 |
| Memory | |
| RAM | 16 GB - DIMM 288-pin - DDR4 SDRAM |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, IGMP, VRRP, PIM-SM, PIM-SSM, MSDP, RIPng, MPLS |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Power Provided | 950 Watt |
| Physical | |
| Width | 44.5 cm |
| Depth | 54.7 cm |
| Height | 4.39 cm |
| Weight | 11.68 kg |
| Environmental | |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| MTBF | 180,640 hours |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1x, UL 60950-1, FCC CFR47 Part 15 |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9500 40-Port 10Gig Network Advantage Switch – Refurbished | C9500-40X-A.
The maximum switching capacity is 480 Gbps.
It has 40 x 10G SFP+ ports.
The forwarding rate is 720 Mpps.
It supports OSPF, BGP, EIGRP, and several others.
The operating temperature range is 0 °C to 40 °C.
Yes, it is designed for enterprise-class core and aggregation layer networks.
