Cisco Catalyst 9200L 24-Port PoE+ Network Essentials Switch – New | C9200L-24P-4X-E
In Stock — Ready to Ship
49 units available
SKU
C9200L-24P-4X-E-NEW
MPN
C9200L-24P-4X-E
$3,783
The Cisco Catalyst 9200L is a new 24-port PoE+ switch ideal for mid-market businesses. Key specs include 740W PoE budget, 4x10G uplinks, and Layer 3 capabilities.
Available via Supplier
Device Type
Switch - 24 ports - L3 - stackable
Enclosure Type
Rack-mountable
Ports
24 x 10/100/1000 (PoE+)
Uplink Ports
4 x 10G SFP+
PoE Budget
740 W
Switching Capacity
128 Gbps
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Catalyst 9200 Series
C9200L-24P-4X-E 24-Port PoE+ Switch New
Designed for secure, efficient networking.
Overview
The Cisco Catalyst 9200L-24P-4X-E is a 24-port Layer 3 switch equipped with Power over Ethernet Plus (PoE+) capabilities. It supports 4x10G uplinks and is designed for mid-market businesses looking to enhance their network infrastructure. This switch leverages Cisco's intent-based networking and offers robust security, automation, and simplified management.
Key Features
- PoE+ Capability: Provides up to 740W PoE budget for powering devices like IP phones and access points.
- Uplink Options: Features 4 x 10G SFP+ uplink ports for high-speed connectivity.
- Layer 3 Functionality: Supports advanced routing protocols including OSPF and EIGRP.
- Stackable Design: Allows for stacking with Cisco StackWise Technology.
- High Performance: Offers a switching capacity of 128 Gbps and a forwarding rate of 190.4 Mpps.
- Robust Security: Integrates Cisco TrustSec for enhanced network security.
- Energy Efficiency: Implements Energy Efficient Ethernet to reduce power consumption.
Specifications
| General | |
|---|---|
| Device Type | Switch - 24 ports - L3 - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Ports | 24 x 10/100/1000 (PoE+) |
| Uplink Ports | 4 x 10G SFP+ |
| PoE Budget | 740 W |
| Performance & Capacity | |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 190.4 Mpps |
| Memory | |
| RAM | 2 GB |
| Flash Memory | 4 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, EIGRP, RIP-1, RIP-2, VRRP, PIM-SM, EIGRP for IPv6 |
| Stacking | |
| Stacking Bandwidth | 80 Gbps |
| Interfaces & Connectivity | |
| Management Interfaces | 1 x console RJ-45, 1 x management (LAN) RJ-45 |
| Power | |
| Power Supply | Internal power supply |
| Power Redundancy | Optional |
| Physical | |
| Width | 17.5 in |
| Depth | 1.7 in |
| Height | 11.3 in |
| Weight | 12.13 lbs |
| Environmental | |
| Operating Humidity | 5 - 90% (non-condensing) |
| Operating Temperature | -5 to 45 °C |
| Storage Temperature | -40 to 158 °F |
| Compliance | |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, RoHS, EN 55022 Class A |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9200L 24-Port PoE+ Network Essentials Switch – New | C9200L-24P-4X-E.
The maximum PoE budget for the C9200L-24P-4X-E is 740W.
The C9200L-24P-4X-E has 24 PoE+ ports.
It features 4 x 10G SFP+ uplink ports.
Yes, it supports stacking with Cisco StackWise Technology.
The switching capacity of the C9200L-24P-4X-E is 128 Gbps.
The dimensions are 17.5 in width, 1.7 in depth, and 11.3 in height.
