Cisco Catalyst 9300 24-Port mGig UPoE+ Network Advantage Switch – New | C9300X-24HX-A
In Stock — Ready to Ship
1 units available
SKU
C9300X-24HX-A-NEW
MPN
C9300X-24HX-A
$14,100
The Cisco Catalyst 9300 24-Port mGig UPoE+ is a new managed switch ideal for enterprises. It features 24 ports, 880 Gbps switching capacity, and a 1835 W PoE budget.
In Stock — Ready To Ship
General
- Device Type: Switch - 24 ports - L3 - managed - stackable
- Enclosure Type: Rack-mountable
Ports & PoE
- Ports: 24 x 100/1000/2.5G/5G/10GBase-T (UPOE+)
- PoE Budget: 1835 W
Performance & Capacity
- Switching Capacity: 880 Gbps
- Switching Capacity with Stacking: 1880 Gbps
- Forwarding Rate: 327.38 Mpps
- Forwarding Rate with Stacking: 1398.8 Mpps
Memory
- RAM: 16 GB
- Flash Memory: 16 GB
Layer & Routing
- Routing Protocols: OSPF, RIP, BGP-4, EIGRP, HSRP, VRRP, PIM-SM, static IP routing
Stacking
- Stacking Bandwidth: 1 TB
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300X-24HX-A 24-Port mGig UPoE+ Switch New
Optimise your network for high-density environments with robust security.
Overview
The Cisco Catalyst 9300 Series switches represent Cisco's leading stackable enterprise access switching platform designed for security, IoT, mobility, and cloud applications. This model is optimised for high-density environments, supporting advanced features for Software-Defined Access (SD-Access). With its robust architecture, it is well-suited for modern enterprise networks that require flexibility and scalability.
Key Features
- High Switching Capacity: Offers 880 Gbps switching capacity and 1880 Gbps with stacking.
- PoE Budget: Supports a PoE budget of 1835 W for powering devices.
- Port Configuration: Includes 24 x 100/1000/2.5G/5G/10GBase-T ports.
- Advanced Routing Protocols: Supports OSPF, BGP-4, EIGRP, and more.
- Memory: Equipped with 16 GB of RAM and 16 GB of flash memory.
- Environmental Resilience: Operates in temperatures from 23°F to 113°F with 5-90% humidity.
- Compact Design: Rack-mountable with dimensions of 17.5 in x 20.6 in x 1.7 in.
Specifications
| General | |
|---|---|
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Ports | 24 x 100/1000/2.5G/5G/10GBase-T (UPOE+) |
| PoE Budget | 1835 W |
| Performance & Capacity | |
| Switching Capacity | 880 Gbps |
| Switching Capacity with Stacking | 1880 Gbps |
| Forwarding Rate | 327.38 Mpps |
| Forwarding Rate with Stacking | 1398.8 Mpps |
| Memory | |
| RAM | 16 GB |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | OSPF, RIP, BGP-4, EIGRP, HSRP, VRRP, PIM-SM, static IP routing |
| Stacking | |
| Stacking Bandwidth | 1 TB |
| Interfaces & Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) |
| USB Ports | 1 x USB 2.0 |
| Power | |
| Power Supply | Internal power supply - hot-plug |
| Physical | |
| Width | 17.5 in |
| Depth | 20.6 in |
| Height | 1.7 in |
| Weight | 13.78 lbs |
| Environmental | |
| Operating Temperature | 23°F to 113°F |
| Storage Temperature | -40°F to 158°F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Compliance | |
| Standards | IEEE 802.3, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300 24-Port mGig UPoE+ Network Advantage Switch – New | C9300X-24HX-A.
The Catalyst 9300 supports a maximum PoE budget of 1835 W.
The Catalyst 9300X has 24 ports supporting 100/1000/2.5G/5G/10GBase-T.
The switching capacity is 880 Gbps and 1880 Gbps with stacking.
Yes, it can be stacked with other Catalyst 9300 and 9300X models.
It supports OSPF, RIP, BGP-4, EIGRP, and more.
It operates in temperatures from 23°F to 113°F with 5-90% humidity.
