Cisco Catalyst 9300 24-Port mGig UPOE+ Network Essentials Switch – New | C9300X-24HX-E
In Stock — Ready to Ship
1 units available
SKU
C9300X-24HX-E-NEW
MPN
C9300X-24HX-E
$7,485
The Cisco Catalyst 9300 24-Port mGig UPOE+ Switch is new and ideal for enterprise networks. It features 24 mGig ports, 880 Gbps switching capacity, and 1835 W PoE budget.
In Stock — Ready To Ship
General
- Device Type: Switch - 24 ports - L3 - managed - stackable
- Enclosure Type: Rack-mountable
Ports & PoE
- Ports: 24 x 100/1000/2.5G/5G/10GBase-T (UPOE+)
- PoE Budget: 1835 W
Performance & Capacity
- Switching Capacity: 880 Gbps
- Switching Capacity with Stacking: 1880 Gbps
- Forwarding Rate: 327.38 Mpps
- Forwarding Rate with Stacking: 1398.8 Mpps
Memory
- RAM: 16 GB
- Flash Memory: 16 GB
Layer & Routing
- Routing Protocols: MSTP, static IP routing, RIP-1, RIP-2, RIPng, PIM-SM, PIM-SSM, GRE, policy-based routing, STP, VRRP, LISP
Stacking
- Stacking Bandwidth: 1 TB with StackWise-1T
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Catalyst 9300 Series
C9300X-24HX-E 24-Port mGig UPOE+ Switch New
Optimized for high-density environments and advanced network management.
Overview
The Cisco Catalyst 9300 Series switches are designed for enterprise environments, focusing on security, IoT, mobility, and cloud integration. Built on an x86 CPU architecture, these switches support advanced features and high-density Wi-Fi 6. They are capable of hosting containers and third-party applications, making them a versatile choice for modern networks.
Key Features
- High-Density Ports: 24 x 100/1000/2.5G/5G/10GBase-T ports with UPOE+ support.
- Switching Capacity: 880 Gbps with stacking capability of 1880 Gbps.
- PoE Budget: 1835 W PoE budget for powering devices.
- Advanced Security: Supports multiple encryption algorithms including AES-256.
- Memory: Equipped with 16 GB RAM and 16 GB flash memory.
- Remote Management: Protocols include NETCONF, RESTCONF, and SNMP.
- Environmental Resilience: Operating temperature range from 23°F to 113°F.
- Compliance Standards: Meets various international safety and performance standards.
Specifications
| General | |
|---|---|
| Device Type | Switch - 24 ports - L3 - managed - stackable |
| Enclosure Type | Rack-mountable |
| Ports & PoE | |
| Ports | 24 x 100/1000/2.5G/5G/10GBase-T (UPOE+) |
| PoE Budget | 1835 W |
| Performance & Capacity | |
| Switching Capacity | 880 Gbps |
| Switching Capacity with Stacking | 1880 Gbps |
| Forwarding Rate | 327.38 Mpps |
| Forwarding Rate with Stacking | 1398.8 Mpps |
| Memory | |
| RAM | 16 GB |
| Flash Memory | 16 GB |
| Layer & Routing | |
| Routing Protocols | MSTP, static IP routing, RIP-1, RIP-2, RIPng, PIM-SM, PIM-SSM, GRE, policy-based routing, STP, VRRP, LISP |
| Stacking | |
| Stacking Bandwidth | 1 TB with StackWise-1T |
| Interfaces & Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) |
| USB Ports | 1 x USB 2.0 |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Power Provided | 1100 Watt |
| Physical | |
| Width | 17.5 in |
| Depth | 20.6 in |
| Height | 1.7 in |
| Weight | 13.78 lbs |
| Environmental | |
| Operating Temperature | 23°F to 113°F |
| Storage Temperature | -40°F to 158°F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Compliance | |
| Compliant Standards | UL 60950-1, EN 60950-1, FCC CFR47 Part 15, RoHS |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco Catalyst 9300 24-Port mGig UPOE+ Network Essentials Switch – New | C9300X-24HX-E.
The maximum PoE budget for the C9300X-24HX-E is 1835 W.
The C9300X-24HX-E has 24 ports.
The switching capacity of the C9300X-24HX-E is 880 Gbps.
Yes, it can be stacked with other Catalyst 9300 and 9300X models.
The operating temperature range is from 23°F to 113°F.
It supports MSTP, static IP routing, RIP-1, RIP-2, RIPng, and more.
