Cisco IE 4000 12-Port Gigabit PoE+ LAN Base Switch – New | IE-4000-4GC4GP4G-E
In Stock — Ready to Ship
1 units available
SKU
IE-4000-4GC4GP4G-E-NEW
MPN
IE-4000-4GC4GP4G-E
$6,175
The Cisco IE 4000 is a new industrial switch designed for harsh environments. It features 12 ports, including 4 PoE+ and 4 combo uplinks. Ideal for manufacturing, energy, and transportation.
In Stock — Ready To Ship
Device Type
Switch - 12 ports - Managed
Enclosure Type
DIN rail mountable
Total Ports
12
PoE Ports
4 x 10/100/1000 (PoE+)
Combo Ports
4 x 1000Base-T RJ-45
MAC Address Table Size
16K entries
Request a quote or add to cart — pricing available on enquiry for refurbished stock.
For international customers, please contact us for personalised support and assistance.
180-Days Warranty
Secure Checkout
Free Delivery US
Dispatch in 1–2 Business Days
Cisco · Industrial Ethernet 4000 Series
IE-4000-4GC4GP4G-E 12-Port Gigabit PoE+ Switch New
Designed for industrial applications with robust performance.
Overview
The Cisco IE 4000 is a managed industrial Ethernet switch built for resilience in harsh environments. It supports advanced security and offers high-bandwidth switching capabilities. With a robust design, it is ideal for applications in manufacturing, energy, and transportation sectors.
Key Features
- 12 Ports: Includes 4 Gigabit PoE+ ports and 4 combo uplink ports.
- Robust Design: Built to withstand extreme industrial conditions.
- Advanced Security: Supports RADIUS and TACACS+ authentication methods.
- High Capacity: Supports up to 1000 VLANs and 1000 IGMP groups.
- Power Over Ethernet: Provides PoE+ capabilities for connected devices.
- Remote Management: Features SNMP, HTTP, and SSH for easy management.
- Environmental Resilience: Operates in temperatures from -40°C to 75°C.
- Compact Size: DIN rail mountable with dimensions of 155.4 x 155.4 x 129.2 mm.
Specifications
| General | |
|---|---|
| Device Type | Switch - 12 ports - Managed |
| Enclosure Type | DIN rail mountable |
| Ports & PoE | |
| Total Ports | 12 |
| PoE Ports | 4 x 10/100/1000 (PoE+) |
| Combo Ports | 4 x 1000Base-T RJ-45 |
| Performance & Capacity | |
| MAC Address Table Size | 16K entries |
| VLANs Supported | 1000 |
| IGMP Groups | 1000 |
| Memory | |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| Layer & Routing | |
| Routing Protocol | Static IPv4 routing |
| Power | |
| Power Consumption | 40 Watt |
| Voltage Required | DC 9.6 - 60 V |
| Electric Current Required | 4.3 A |
| Physical | |
| Width | 155.4 mm |
| Depth | 129.2 mm |
| Height | 155.4 mm |
| Weight | 2.88 kg |
| Environmental | |
| Operating Temperature | -40 °C to 75 °C |
| Storage Temperature | -40 °C to 85 °C |
| Humidity Range | 5 - 95% (non-condensing) |
| Compliance | |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, EN 55024, RoHS |
Product information is automatically compiled from trusted manufacturers and data providers. Please. report any errors.
Write Your Own Review
Common questions about the Cisco IE 4000 12-Port Gigabit PoE+ LAN Base Switch – New | IE-4000-4GC4GP4G-E.
The maximum operating temperature is 75 °C.
The Cisco IE 4000 can support up to 1000 VLANs.
Yes, it supports PoE+ with 4 ports providing power to connected devices.
The weight of the switch is 2.88 kg.
Yes, it supports remote management protocols such as SNMP, HTTP, and SSH.
It is designed for harsh industrial environments, including manufacturing and energy sectors.
